Merck

13607

Diaion® HP-20

pkg of 1000 g

Sign In to View Organizational & Contract Pricing.

Select a Size

All Photos(1)

About This Item

CAS Number:
9052-95-3
MDL number:
MFCD00146442
UNSPSC Code:
23151817
NACRES:
NB.21

Product Name

Diaion® HP-20, pkg of 1000 g

matrix active group

polymer

SMILES string

C(C)c3c(cccc3)C=C.c2(c(cccc2)C=C)C=C.c1(ccccc1)C=C

InChI

1S/C10H12.C10H10.C8H8/c2*1-3-9-7-5-6-8-10(9)4-2;1-2-8-6-4-3-5-7-8/h3,5-8H,1,4H2,2H3;3-8H,1-2H2;2-7H,1H2

InChI key

NWUYHJFMYQTDRP-UHFFFAOYSA-N

form

solid

packaging

pkg of 1000 g

technique(s)

HPLC: suitable
LPLC: suitable
ion chromatography: suitable
thin layer chromatography (TLC): suitable

surface area

~500 m2/g

matrix

styrene-divinylbenzene

particle size

250-850 μm

pore size

~1.30 mL/g pore volume
260 Å mean pore size

density

1.01 g/mL at 25 °C (true wet)(lit.)

separation technique

reversed phase

Quality Level

100

Looking for similar products? Visit Product Comparison Guide

Related Categories

Application

Polyaromatic adsorbent resin for hydrophobic compounds: antibiotics, biomolecules; useful for desalting; broad application base.
  • Diaion® HP-20 was used as adsorbent for open column chromatography.
  • Diaion® HP-20 was used in purification of glucosides using TLC and HPLC analysis.

General description

Diaion® HP-20 is a non-polar copolymer styrene-divynilbenzene adsorbent resin. It is a polymeric adsorbent used in reverse phase chromatography. It has spherical particles with 0.5mm diameter. Diaion HP-20 is considered as the most effective adsorbent to eliminate toxic effects in fermentation. It is a synthetic adsorbent used for preconcentration and separation of traces heavy metal ions.

Other Notes

Swelling in toluene = 30%

Legal Information

Diaion is a registered trademark of Mitsubishi Chemical Corp.

Storage Class

11 - Combustible Solids

wgk

WGK 3

flash_point_f

Not applicable

flash_point_c

Not applicable

ppe

Eyeshields, Gloves, type N95 (US)

Choose from one of the most recent versions:

Certificates of Analysis (COA)

Lot/Batch Number
203703
199092
198319
197496
195928

Don't see the Right Version?

If you require a particular version, you can look up a specific certificate by the Lot or Batch number.

Search for a COA

Already Own This Product?

Find documentation for the products that you have recently purchased in the Document Library.

Visit the Document Library

Hiroaki Inoue et al.
Applied and environmental microbiology, 68(10), 4809-4811 (2002-09-27)
The addition of HP-20 resin to a medium could enhance the growth of Legionella species. Elemental sulfur was isolated as a self-growth-inhibiting substance produced endogenously by Legionella pneumophila from methanol extracts of the resins used to culture the bacterium. Elemental
B Jiang et al.
Journal of ethnopharmacology, 96(3), 521-528 (2004-12-28)
Ethnopharmacological collections of plants used in traditional medical systems are a valuable but often underappreciated resource for scientific investigation. These collections contain many samples of plants currently employed in herbal and pharmaceutical medicine, and questions on stability and storage life
J C Lee et al.
Letters in applied microbiology, 37(3), 196-200 (2003-08-09)
To use adsorbent resins in fermentations to eliminate toxic effects on growth, reduce feedback repression of production and assist in recovery of teicoplanin. An adsorbent resin was added to the culture broth for the adsorption of teicoplanin. Amberlite XAD-16, Diaion
Investigation of Reverse Phase SMB-Chromatographic Bioseparations of Amino Acid Aqueous Solutions.
Molnar, Z., et al
Hungarian Journal of Industrial Chemistry, 32.1, 23-23 (2004)
Ana Andres-Hernando et al.
American journal of physiology. Endocrinology and metabolism, 319(2), E276-E290 (2020-06-24)
Intake of sugars, especially the fructose component, is strongly associated with the development of obesity and metabolic syndrome, but the relative role of taste versus metabolism in driving preference, intake, and metabolic outcome is not fully understood. We aimed to
