685445
Halloysite Nanoclay
Sinónimos:
Kaolin clay
Iniciar sesión para ver los precios por organización y contrato.
Seleccione un Tamaño
Cambiar Vistas
Acerca de este artículo
Fórmula lineal:
Al2Si2O5(OH)4 · 2 H2O
Número CAS:
Peso molecular:
294.19
NACRES:
NA.23
PubChem Substance ID:
UNSPSC Code:
12162002
EC Number:
310-194-1
MDL number:
Form:
nanopowder
Servicio técnico
¿Necesita ayuda? Nuestro equipo de científicos experimentados está aquí para ayudarle.
Permítanos ayudarleform
nanopowder
Quality Level
diam. × L
30-70 nm × 1-3 μm , nanotube
surface area
64 m2/g
color
75-96, Hunter Brightness
refractive index
n20/D 1.54
pore size
1.26-1.34 mL/g pore volume
capacity
8.0 meq/g cation exchange capacity
density
2.53 (true specific gravity)
SMILES string
O.O.O[Si](O)(O[Al]=O)O[Si](O)(O)O[Al]=O
InChI
1S/2Al.H4O7Si2.2H2O.2O/c;;1-8(2,3)7-9(4,5)6;;;;/h;;1-2,4-5H;2*1H2;;/q2*+1;-2;;;;
InChI key
HEFIDAICLOZRRO-UHFFFAOYSA-N
General description
Halloysite nanoclay has a tube like morphology. It shows low electrical, thermal conductivity and strong hydrogen interactions, on account of which the inner hydroxyl groups show greater stability than the surface hydroxyl groups in halloysite. The loss of hole water occurs at nearly 300 °C.
Similar to montmorillonite, halloysite consists of two layers of aluminosilicate in 1:1 Al:Si ratio. Significant improvements in thermal, mechanical properties have been reported on addition of halloysite nanotubes in polymer composites.
Similar to montmorillonite, halloysite consists of two layers of aluminosilicate in 1:1 Al:Si ratio. Significant improvements in thermal, mechanical properties have been reported on addition of halloysite nanotubes in polymer composites.
Application
Halloysite is frequently used as a reinforcement in various nanocomposites, some of which are listed here:
Isotactic propylene-halloysite nanocomposites.
Alloy composites by electroless/ autocatalytic deposition.
Poly(butylene terephthalate) (PBT) composites.
Zinc–halloysite nanotube (HNT) composite coatings.
Halloysite nanotube–hydroxyapatite–hyaluronic acid films.
Halloysite combined with polyamide, polypropylene, poly(ε-caprolactone) and fluroelastomers.
Its tube like morphology, high aspect ratio, and low percolation enables interesting applications as reinforcements in nanocomposites.
Isotactic propylene-halloysite nanocomposites.
Alloy composites by electroless/ autocatalytic deposition.
Poly(butylene terephthalate) (PBT) composites.
Zinc–halloysite nanotube (HNT) composite coatings.
Halloysite nanotube–hydroxyapatite–hyaluronic acid films.
Halloysite combined with polyamide, polypropylene, poly(ε-caprolactone) and fluroelastomers.
Its tube like morphology, high aspect ratio, and low percolation enables interesting applications as reinforcements in nanocomposites.
Legal Information
Product of Applied Minerals, Inc. Customers may obtain additional technical support and purchase commercial quantities at appliedminerals.com
Clase de almacenamiento
11 - Combustible Solids
wgk
nwg
flash_point_f
Not applicable
flash_point_c
Not applicable
ppe
Eyeshields, Gloves, type N95 (US)
Elija entre una de las versiones más recientes:
¿Ya tiene este producto?
Encuentre la documentación para los productos que ha comprado recientemente en la Biblioteca de documentos.
Raman spectroscopy of isotactic polypropylene-halloysite nanocomposites
Ibrahim EE, et al.
Journal of Nanomaterials, 12 (2012)
Du M. et al.
Eur. Polymer J., 42, 1362-1362 (2006)
Wagner A. et al.
Industrial Biotechnology (New Rochelle, N.Y.), 1, 190-190 (2005)
