Zirconium(IV) oxide-yttria stabilized

Name: Zirconium(IV) oxide-yttria stabilized
Brand: ALDRICH

sputtering target, diam. × thickness 2.00 in. × 0.25 in., 99.9% trace metals basis

Synonym(s):

8YSZ, YSZ8, YSZ, Yttria stabilized zirconia, Yttrium stabilized zirconium oxide

Select a Size

All Photos(1)

About This Item

Linear Formula:

ZrO_{2 ·}Y₂O₃

CAS Number:

114168-16-0

Molecular Weight:

349.03

NACRES:

NA.23

PubChem Substance ID:

329767658

UNSPSC Code:

12352300

MDL number:

MFCD00145546

Product Name

Zirconium(IV) oxide-yttria stabilized, sputtering target, diam. × thickness 2.00 in. × 0.25 in., 99.9% trace metals basis

InChI key

KSTOPEBVPBSOTK-UHFFFAOYSA-N

SMILES string

O=[Zr]=O.O=[Y]O[Y]=O

InChI

1S/5O.2Y.Zr

assay

99.9% trace metals basis

form

solid

contains

8 mol % yttria as stabilizer

composition

(ZrO₂)_0.92(Y₂O₃)_0.08

reaction suitability

core: zirconium

diam. × thickness

2.00 in. × 0.25 in.

mp

>2,600 °C (lit.)

Looking for similar products? Visit Product Comparison Guide

Application

Electrolyte material for solid oxide fuel cells (SOFC).

Solid Oxide Fuel cells operating at temperatures below 800 C (also known as intermediate temperature solid oxide fuel cell, IT-SOFC) are currently the topic of much research and development owing to the high degradation rates and materials costs incurred for SOFC operating at temperatures above 900 C. Thin films of electrode and electrolyte layers is one of the ways to achieve high performances in IT-SOFC. 8 mol% yttria stabilized zirconia sputtering targets can be used to deposit thin films of YSZ layers with high electronic conductivities.

pictograms

GHS07

signalword

Warning

hcodes

H315,H319,H335

pcodes

P261 - P305 + P351 + P338

Hazard Classifications

Eye Irrit. 2 - Skin Irrit. 2 - STOT SE 3

target_organs

Respiratory system

Storage Class

13 - Non Combustible Solids

wgk

WGK 3

flash_point_f

Not applicable

flash_point_c

Not applicable
