901090
Silver nanoparticles ink for screen printing
low curing temperature
Synonym(s):
Ag ink, Conductive ink, Smart’Ink C47NSCR09003 conductive ink
Sign In to View Organizational & Contract Pricing.
Select a Size
Change View
About This Item
Linear Formula:
Ag
NACRES:
NA.23
UNSPSC Code:
12141740
description
Electrodes
Quality Segment
form
viscous liquid (paste)
viscosity
4,400-6,400 mPa.s(20 °C) (at 100 s-1), 6,400-10,000 mPa.s(20 °C) (at 40 s-1)
capacity
55±5 % loading (Nanoparticles loading)
storage temp.
2-8°C
General description
Smart’Ink C47NSCR09003 conductive ink developed for printed electronics market is particularly well suited for applications requiring high conductivity and high resolution at very low curing temperatures. This ink, based on silver, is perfectly adapted to design conductive tracks on flexible substrates and is suitable to produce antennas for IoT applications (HF, UHF).
This ink has been developed to address the applications which require very low curing temperatures.
This ink has been developed to address the applications which require very low curing temperatures.
Product benefits:
- Very high electrical conductivity.
- Very low curing temperature for printing on flexible substrates.
- Non CMR ink.
- Unchanged conductivity on bending.
- Compatible with various curing processes including photonic, IR, low vacuum oven and thermal.
- Good adhesion on various flexible substrates (PET, Kapton®, …).
Preparation Note
Typical processing guideline:
- Smart’Ink C47NSCR09003 conductive ink needs to be agitated before use.
- Ready to use. No need to use thinner.
Other Notes
Resistivity: ≤1 mΩ/sq, per 25 μm (screen printed on PET, curing at 200 °C/5 min)
≤3 mΩ/sq, per 25 μm (screen printed on PET, curing at 120 °C/5 min)
≤4 mΩ/sq, per 25 μm (screen printed on PET, curing at 80 °C/5 min)
≤5 mΩ/sq, per 25 μm (screen printed on PET, curing at 60 °C/5 min)
≤3 mΩ/sq, per 25 μm (screen printed on PET, curing at 120 °C/5 min)
≤4 mΩ/sq, per 25 μm (screen printed on PET, curing at 80 °C/5 min)
≤5 mΩ/sq, per 25 μm (screen printed on PET, curing at 60 °C/5 min)
Legal Information
Product of Genes′Ink
Kapton is a registered trademark of E. I. du Pont de Nemours and Company
signalword
Warning
Storage Class
10 - Combustible liquids
flash_point_f
199.4 °F
flash_point_c
93 °C
target_organs
Nervous system
Hazard Classifications
Aquatic Acute 1 - Aquatic Chronic 1 - Eye Irrit. 2 - Repr. 2 - Skin Irrit. 2 - STOT RE 2
