TLC aluminum sheets, Kieselguhr F₂₅₄

Name: TLC aluminum sheets, Kieselguhr F₂₅₄
Brand: MM

pkg of 25 sheets, sheet L × W 20 cm × 20 cm, aluminum support

Synonym(s):

Kieselguhr Coated TLC Plates

Select a Size

All Photos(1)

About This Item

NACRES:

NB.21

UNSPSC Code:

41115711

Product Name

TLC aluminum sheets, Kieselguhr F₂₅₄, pkg of 25 sheets, sheet L × W 20 cm × 20 cm, aluminum support

material

aluminum support
silica gel 60 matrix

feature

binder Organic Polymer
fluorescent indicator

packaging

pkg of 25 sheets

technique(s)

thin layer chromatography (TLC): suitable

layer thickness

200 μm

plate L × W

20 cm × 20 cm

sheet L × W

20 cm × 20 cm

particle size

10-12 μm

pore size

60 Å medium pore diameter

storage temp.

2-30°C

Quality Level

100

Related Categories

Analytical Chromatography

Thin Layer Chromatography (TLC)

Analysis Note

Layer thickness: 170 - 220 µm
Deviation of layer thickness per plate: ≤ 30 µm
Chromatographic testing:
amino acid test
hRf-values
- β-alanine, short-time test:
25 - 30
- L-alanine, amino acid test: 45 - 55
- DL-Valin, amino acid test: 75 - 85
- L-leucine, amino acid test: 85 - 95
Typical value determined on a sheet
Eluent: n- propanol/ water (80/20 v/v)

General description

25 Aluminium sheets 20 x 20 cm

Precoated Kieselguhr or mixed Silica gel/Kieselguhr plates are only of small importance nowadays. Kieselguhr layers are used like cellulose layers for the TLC separation of polar and moderately polar substances. Polyamide, on the other hand , is used for the separation of flavonoids and other phenolic substances.

Other Notes

Replaces: 5568-7; 5568
