5.08510

ZD 7288

Synonym(s):

ZD 7288, 4-(N-ethyl-N-phenylamino)-1,2-dimethyl-6-(methylamino)pyrimidiniumchloride, Zeneca, HCN Channel Blocker, ZD 7288, ZD-7288, ZD7288

Sign In to View Organizational & Contract Pricing.

Select a Size

About This Item

Empirical Formula (Hill Notation):
C15H21ClN4
CAS Number:
133059-99-1
Molecular Weight:
292.81
MDL number:
MFCD29919955
UNSPSC Code:
12352200
NACRES:
NA.77

Key Documents

View All Documentation
Technical Service
Need help? Our team of experienced scientists is here for you.
Let Us Assist
Technical Service
Need help? Our team of experienced scientists is here for you.
Let Us Assist

SMILES string

Cl.[n]1([c](cc(nc1C)N(CC)c2ccccc2)=NC)C

InChI

1S/C15H20N4.ClH/c1-5-19(13-9-7-6-8-10-13)15-11-14(16-3)18(4)12(2)17-15;/h6-11H,5H2,1-4H3;1H

InChI key

DUWKUHWHTPRMAP-UHFFFAOYSA-N

assay

≥98% (HPLC)

form

solid

manufacturer/tradename

Calbiochem®

storage condition

OK to freeze
protect from light

color

white

solubility

water: 100 mM

storage temp.

2-8°C

Quality Level

100

Related Categories

Biochem/physiol Actions

Primary Target
HCN channel

Disclaimer

Toxicity: Standard Handling (A)

General description

ZD7288 is a potent HCN blocker of hyperpolarization-activated cyclic nucleotide-gated channels (HCN channels) in heart and brain tissue. Recently shown to also block Na+ currents in DRG neurons and in HEK293 cells transfected with Na(v)1.4 plasmids. In voltage clamp experiments, it is shown to reduce Ih in a time- and concentration-dependent manner (IC50 = 2 mM). Suggested to behave as a lipophilic quaternary cation that can pass into the cell interior to block Ih channels in their closed state.

Other Notes

Pleasenote that the molecular weight for this compound is batch-specific due tovariable water content.

Preparation Note

Following reconstitution, aliquot and freeze (-20°C). Stock solutions are stable for up to 3 months at -20°C.

Legal Information

CALBIOCHEM is a registered trademark of Merck KGaA, Darmstadt, Germany

Storage Class

11 - Combustible Solids

wgk

WGK 3

flash_point_f

Not applicable

flash_point_c

Not applicable

Certificates of Analysis (COA)

Search for Certificates of Analysis (COA) by entering the products Lot/Batch Number. Lot and Batch Numbers can be found on a product’s label following the words ‘Lot’ or ‘Batch’.

Already Own This Product?

Find documentation for the products that you have recently purchased in the Document Library.

Visit the Document Library

Xing Wu et al.
Channels (Austin, Tex.), 6(6), 438-442 (2012-09-20)
ZD7288 has been widely used as a tool in the study of hyperpolarization-activated cyclic nucleotide-gated channels (HCN channels), and to test the relationships between HCN channels and heart and brain function. ZD7288 is widely considered a selective blocker of HCN
N C Harris et al.
Journal of neurophysiology, 74(6), 2366-2378 (1995-12-01)
1. The effects of the novel bradycardic agent 4-(N-ethyl-N-phenylamino)-1,2-dimethyl-6-(methylamino) pyrimidinium chloride (ZD 7288) (Zeneca) were investigated on the hyperpolarization-activated cationic current (Ih) in guinea pig substantia nigra pars compacta neurons in vitro, using a single-microelectrode current-clamp/voltage-clamp technique. 2. Under current-clamp
