467634

Barium titanate(IV)

Name: Barium titanate(IV)
Brand: ALDRICH

nanopowder (cubic crystalline phase), <100 nm particle size (BET), ≥99% trace metals basis

Synonym(s):

Barium titanium oxide, Titanium barium oxide

Select a Size

Change View

About This Item

Linear Formula:

BaTiO₃

CAS Number:

12047-27-7

Molecular Weight:

233.19

NACRES:

NA.23

PubChem Substance ID:

24870427

UNSPSC Code:

12352302

EC Number:

234-975-0

MDL number:

MFCD00003447

Technical Service

Need help? Our team of experienced scientists is here for you.

Let Us Assist

Properties

Quality Level

100

assay

≥99% trace metals basis

form

nanopowder (cubic crystalline phase)

dielectric constant

150

reaction suitability

reagent type: catalyst
core: titanium

particle size

<100 nm (BET)

density

6.08 g/mL at 25 °C (lit.)

SMILES string

[Ba++].[O-][Ti]([O-])=O

InChI

1S/Ba.3O.Ti/q+2;;2*-1;

InChI key

WNKMTAQXMLAYHX-UHFFFAOYSA-N

Description

General description

Barium titanate(IV) is a ceramic material that can be synthesized by reacting titanium oxide (TiO₂) and barium salts in the presence of oleic acid as a stabilizing agent. It has a cubic crystal structure which allows it to have ferroelectric, thermoelectric and piezoelectric properties. It forms a film with intense photoluminescence which can be used for a wide range of electronic applications.

Application

BaTiO₃ can be used in the fabrication of flexible electronic devices with improved dielectric strength.

Physical form

Some agglomeration of nanoparticles may occur during the drying process, yielding particle sizes of up to 75 microns. These agglomerates can be broken up through ultrasonication, ball milling, or dispersion in solution with a surfactant.
