791881
Conductive silver printing ink, resistivity 9 - 10 μΩ-cm
別名:
Greatcell Solar®, Dyesol® DYAG100 conductive silver ink, Screen printable silver paste
ログインで組織・契約価格をご覧ください。
サイズを選択してください
表示を変更する
この商品について
NACRES:
NA.23
UNSPSC Code:
12352103
Quality Segment
description
Electrodes, volume resistivity 9 - 10 μΩ-cm
assay
75-85% (Solids content)
form
paste (white)
viscosity
9000-12000 mPa.s (at shear rate of 10 sec-1 at 25°C)
General description
Sheet Resistivity is 3.6 - 4 mΩ / square / mil. (at a 180°C cure temperature)
Application
Use this Conductive Silver Ink to achieve outstanding conductivity at low cure temperatures when printing on a variety of substrates, including glass and polyesters (PET/PEN) and ITO/FTO coated substrates.
This Conductive Silver Printing Ink provides outstanding conductivity at low cure temperatures. It provides extremely low resistance of printed conducting tracks, essential for the photovoltaic applications, and is a key enabler in plastic electronics such as DSSC; OPV; CdTe solar cells etc.,by providing lowest track resistances of printed current collectors.
The Conductive Silver Printing Ink is comprised of a mixture of pure silver particles and an organometallic silver compound in an organic medium. When printed on polyester films, and then heated to 160 - 180°C, the particles consolidate to form a chemically-welded, continuous metal track.
This Conductive Silver Printing Ink provides outstanding conductivity at low cure temperatures. It provides extremely low resistance of printed conducting tracks, essential for the photovoltaic applications, and is a key enabler in plastic electronics such as DSSC; OPV; CdTe solar cells etc.,by providing lowest track resistances of printed current collectors.
The Conductive Silver Printing Ink is comprised of a mixture of pure silver particles and an organometallic silver compound in an organic medium. When printed on polyester films, and then heated to 160 - 180°C, the particles consolidate to form a chemically-welded, continuous metal track.
Legal Information
Product of Greatcell Solar Materials Pty Ltd.
Greatcell Solar is a registered trademark of Greatcell Solar Materials Pty Ltd.
Greatcell Solar is a registered trademark of Greatcell Solar Materials Pty Ltd.
Dyesol is a registered trademark of Greatcell Solar
Greatcell Solar is a registered trademark of Greatcell Solar
signalword
Warning
hcodes
Hazard Classifications
Aquatic Acute 1 - Aquatic Chronic 1 - Eye Irrit. 2 - Skin Irrit. 2
保管分類
10 - Combustible liquids
wgk
WGK 3
flash_point_f
174.2 °F
flash_point_c
79 °C
