1.04699
Immersion oil
for microscopy
ログインで組織・契約価格をご覧ください。
サイズを選択してください
表示を変更する
この商品について
NACRES:
NA.21
UNSPSC Code:
41122605
Quality Segment
form
liquid
IVD
for in vitro diagnostic use
color
light yellow
refractive index
n
density
1.02 g/cm3 at 20 °C
application(s)
diagnostic assay manufacturing
hematology
histology
microbiology
storage temp.
15-25°C
General description
Immersion Oil - for Microscopy, is of an oily nature and has a defined refractive index of about 1,516. It is important that the refractive index (nD) is about 1.5, similar to that of glass. This enables a homogeneous oil immersion to be achieved. Immersion media are used in conjunction with immersion objectivs and are located between the surface of the specimen and the lens of the microscope. Immersion oils practically eliminate light beam deflection so that the effectiveness of the lens is considerably increased. Immersion Oil - for Microscopy is produced from a natural component and developed, certified and registered as CE / IVD product. For more details, please see instructions for use (IFU). The IFU can be downloaded from this webpage.
1046990001 is in drip plastic bottle and 1046990100 is 100ml in glass bottle.
1046990001 is in drip plastic bottle and 1046990100 is 100ml in glass bottle.
Analysis Note
Refractive index (n 20/D): 1.515 - 1.517
Density (d 20 °C/ 4 °C): 1.0245 - 1.0265
Transmission (380 nm; 1 cm): ≥ 65 %
Transmission (400 nm; 1 cm): ≥ 78 %
Transmission (450 nm; 1 cm): ≥ 90 %
Fluorescence (as quinine at 365 nm): ≤ 1500 ppb
Viscosity (20 °C): 100 - 120 mPa∙s
Suitability for microscopy: passes test
Density (d 20 °C/ 4 °C): 1.0245 - 1.0265
Transmission (380 nm; 1 cm): ≥ 65 %
Transmission (400 nm; 1 cm): ≥ 78 %
Transmission (450 nm; 1 cm): ≥ 90 %
Fluorescence (as quinine at 365 nm): ≤ 1500 ppb
Viscosity (20 °C): 100 - 120 mPa∙s
Suitability for microscopy: passes test
Still not finding the right product?
Explore all of our products under Immersion oil
signalword
Warning
hcodes
pcodes
Hazard Classifications
Aquatic Acute 1 - Aquatic Chronic 2
保管分類
10 - Combustible liquids
