ATTP02500 Isopore Membrane Filter

0.8 µm pore size, hydrophilic polycarbonate membrane, 25 mm diameter

View Products on Sigmaaldrich.com
ATTP02500
polycarbonate, Hydrophilic, 0.8 µm, 25 mm, white, plain, 100
Retrieving price...
Price could not be retrieved
Minimum Quantity is a multiple of
Maximum Quantity is
Upon Order Completion More Information
You Saved ()

—
Request Pricing
—
Limited Availability Limited Availability
In Stock
Discontinued
Limited Quantities Available
Availability to be confirmed
    Remaining : Will advise
      Remaining : Will advise
      Will advise
      Contact Customer Service
      Contact Customer Service



      Contact Customer Service

      Overview

      Replacement Information
      Description
      Catalogue NumberATTP02500
      Trade Name
      • Isopore
      DescriptionIsopore Membrane Filter
      Background InformationThe Isopore™ membrane is a polycarbonate, track-etched screen filter recommended for all analyses in which the sample is viewed on the surface of the membrane. Isopore™ membrane offers distinct advantages for the analysis of airborne contaminants and other particles using optical or electron microscopy. The Isopore™ membrane is composed of polycarbonate film, which has a smooth, glass-like surface for clearer sample observation. The unique manufacturing process of the membrane ensures a precise pore diameter and a consistent pore size for accurate separation of samples by size. Matched-weight filters are not usually required because of low, constant tar and ash weights.

      Features & Benefits:
      •Membrane structure retains particles on the surface, simplifying counting and analysis
      •Isopore™ membranes do not stain, resulting in low background interference
      •Non-hygroscopic, allowing for rapid drying and reduced sample analysis time
      •Translucent material does not require clearing for transmitted light microscopy; also available in brown variety

      Applications:
      Air Monitoring, Epifluorescent Microscopy, Chemotaxis Assays
      References
      Product Information
      HS Code3926 90 40
      Filter CodeATTP
      Filter ColorWhite
      Maximum Operating Temperature140 °C (possible reduction in flow rates may occur after autoclaving)
      Filter TypeScreen filter
      Applications
      Application0.8 µm pore size, hydrophilic polycarbonate membrane, 25 mm diameter
      Biological Information
      MediaIsopore®
      WettabilityHydrophilic
      Physicochemical Information
      Refractive Index1.6
      Pore Size0.8 µm
      Air Flow Rate4.08 L/min x cm²/psi
      Bubble Point at 23 °C≥1.17 bar, air with water
      Gravimetric Extractables< 1%
      Porosity %5%–20%
      Water Flow Rate
      • Avg. 85 mL/min x cm² (typical results at 10 psi)
      • 125 mL/min x cm²/psi
      Dimensions
      Filter SurfacePlain
      Thickness25 µm
      Filter Diameter (⌀)25 mm
      Materials Information
      Chemistry
      • Polycarbonate (PC)
      Toxicological Information
      Safety Information according to GHS
      Safety Information
      Product Usage Statements
      Storage and Shipping Information
      Packaging Information
      Material Sizepolycarbonate, Hydrophilic, 0.8 µm, 25 mm, white, plain, 100
      Transport Information
      Supplemental Information
      Specifications
      Global Trade Item Number
      Catalogue Number GTIN
      ATTP02500 04053252405136
